Flake Ice Machine On Board SFM50W(5T/D)

NO.SFM50W

Flake Ice Machine On Board SFM50W(5T/D)

NO.SFM50W

Product Description Technical Parameters

Application Fields
Fisheries industry
Sea food preservation
Product Features
According to standard of pressure vessel to design and manufacture of ice maker, solid, safe and reliable;
Direct low temperature continuous ice-making, ice temperature can be reached to -10 ℃, high efficiency;
Degree of supercooling of flake ice is good, dry, thickness is reached to 2.5 mm;
Optimal Designing of refrigeration system,stable operation and low failure rate;
Using environmental protection refrigerants, environmental protection, high efficiency and energy saving
Using the special way of water supply and refrigeration system design, the biggest can be withstanding 35 ° rocking degree.
Evaporator & base using alloy materials such as stainless steel, corrosion resistance, long service life;
Electric control panel,circuit meet the Marine electrical standards, anti-corrosion, high security;
Full automatic control, ice full automatic stop, realizing unattended;
Beautiful shape, the overall rational layout, details, strive for perfection.

Operating conditions
Power Requirements: International general standard of the whole system of electric power supply
Standard working conditions of ice production: water supply temperature 20 ℃, ambient temperature 33 ℃
Applicative operating mode, water temperature 0 to 35 ℃, ambient temperature  5 ~ 40 ℃
Ice outlet temperature:-10℃,惹 refrigerant:R404A,R507A
Performance parameters
Ice Output:1600kg/d
Refrigeration capacity:6KCal
Condensing temperature:38℃;
Evaporating temperature:-28℃
Water pump:0.04kw
Reducer:0.37kw
Running power consumption:5.6kw
Installed power:6.5kw
Water consumption of ice making:67L/H
Ice falling outlet ?:460mm
Overall dimensions: L1420mm*W1150mm*H1305mm
Weight:900KG
(Due to technical innovation,the above parameters will be changed ,If necessary, please contact our sales office)
